UPF, AMF, SMF, PCF, UDM, AF
CU, DU, OAM, Platform
5G MEC, Connected Car, 5G Network Slicing App
Component, Solution, Manual, Automation
Software Development, Network Development
5G PoC Implement, Integration, Testing
eMBB, uRLLC, mmWave
O-RAN (Open RAN)
Network Slicing
Edge Computing
VNF, NFV, K8S Cloud
DevOps:
Jenkins, CI/CD
Jenkins, CI/CD
Programming:C/C++, Java, Python, Go
SDN, Networking
Automation:
Robot Framework, Python
Robot Framework, Python
Protocols:
HTTP/2, TLS, TCP, UDP, SCTP, IP, GTP, NG-AP, NAS, PFCP, RRC, PDCP, SDAP, RLC, F1AP, E2AP, XnAP.
HTTP/2, TLS, TCP, UDP, SCTP, IP, GTP, NG-AP, NAS, PFCP, RRC, PDCP, SDAP, RLC, F1AP, E2AP, XnAP.
To properly enable new 5G applications, it’s important to have a 5G Lab with sufficient functionality to understand and experience the actual capability in a 5G Network.
Hardware
- PC i7 (X86 HW)
- USRP B120/N300
- Adlinktech MECS-6110
Software
- gNB: OAI gNB
- 5GC: Open 5GS
Bandwidth (UL/DL)
- 100 MHZ
- 30 Mbps - 330 Mbps
UE
- Quectel: RM500Q-GL
- XR-90 or 5G Phone
License (OAI Public License)
- License V1.1
5G NR SA TDD Configuration
- Frequency band: n78
- SCS: 30kHz
- Uplink-Configurations: 64QAM max
- Downlink Configurations: 256QAM max
UE
N300
B210
PC
Adlinktech MECS-6110- Window Application‘s functions:
- Start multiple PDU sessions to different 5G network slices
- Automatically route app traffic to appropriate 5G
network slices - Window Application‘s key features:
- Manage Interface, Profile
- Manage Routing Policy for specific application
- Display network connection characteristics
- Automatically switch network slice based on APN and
Routing Policy
- Practical Application
- Provide an application deployment platform close to the end users. This MEC platform helps to deploy real-time, compute and resource-intensive applications like video caching, augmented reality, virtual reality, and Internet of Things at the edge
- Help decrease workload & congestion at 5G Core site
- PoC Description
- Follow ETSI standard
- 5G Core Network (gNdB, Core), 5G Apps
- MEC system: MEC Platform (MEP), MEP
Manager, MEC Orchestrator
- Application Functions
- Control accelerator/brake to increase/decrease speed
- Control Steering wheel
- Turn on/off lights, trumpets
- Turn on driver assistance features like Cruise Control
- Video streaming
Connected Car (by Remote Control) - Car is connected to 5G network and can be controlled remotely by mobile app or window app:
- Technologies
- Computer vision and AI image recognition
- C/C++, Python, OpenCV
- ECU programming
- Protocol: CAN, TCP/IP, USB, Ethernet
- Wireless: 5G, Wifi
- Application Functions
- Object Detection: people, vehicle, specific objects
- Face Recognition, Age/Gender Detection
- Extract and store information from video/stream
- Behavior analysis
- Active observation & incident warning
- License Plate Recognition
- Text/Digit Detection and Recognition (OCR)
- Edge processing and Centralized processing
- Network connection with private 5G network
- Technologies
- Computer Vision
- Image Processing
- Deep Learning
- Object Tracking, Multiple Camera Processing
- Python, OpenCV, Tensorflow, Pytorch, Caffee, TensorRT, OpenVINO, Onnx
- Restful API, MQTT
